- Country
- Great Britain (UK)
- Manufacturer / Brand
- Halcyon Wireless; London
- Year
- 1936 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 200895
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 130.5 kHz
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 200-260 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: A581 - Halcyon Wireless; London
- Shape
- Tablemodel, low profile (big size).
- Notes
- Flywheel tuning. An optional remote volume control unit was available. An almost identical chassis is fitted to the Halcyon RGA581 radiogram. In Trader 217, p.1 an AP4V is mentioned. That must be an APV4 (as listed on p.3, valve analysis).
- Literature/Schematics (1)
- Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (217)
- Author
- Model page created by Howard Craven. See "Data change" for further contributors.
