• Year
  • 1958 ?
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 177499

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 13
  • Valves / Tubes
  • Main principle
  • Superhet with RF-stage
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Alternating Current supply (AC) / 110 - 120 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: 1790P Ch= A2014 - Hallicrafters, The; Chicago,
  • Shape
  • Tablemodel, with any shape - general.
  • Notes
  • Television Receiver, Picture tube: 17CFP4,
    Tuning Range: TV - Channels 2 thru 13.
  • Author
  • Model page created by Egon Penker. See "Data change" for further contributors.
