• Country
• United States of America (USA)

• Manufacturer / Brand
• Hallicrafters, The; Chicago, IL and Arlington/Grand Prairie, TX

• Year
• 1955 ?

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 302330

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 18

• Valves / Tubes
• 6BZ7 6AF4 6U8 6CB6 6CB6 6AM8 6AU8 6BN6 6V6GT 6CN7 6BY6 6CG7 6S4A 6SN7GT 6CU6 6AX4GT 1X2B 21ALP4A or 24DP4A

• Main principle
• Superhet with RF-stage

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 60 cycles, 117V = 110 -120 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 24TT511B Ch= D2000D - Hallicrafters, The; Chicago,

• Shape
• Console, Lowboy (legs < 50 %).

• Notes

• Hallicrafters model 24TT511B is a 24" b/w TV with US standard VHF tuner channels 2 thru 13, and 14 thru 83 UHF. Equipped with chassis D2000D, VHF-UHF tuner ID2480 and picture tube 24DP4A.

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (set 321 Folder 6 dated 6-56)

• Author
• Model page created by Dirk Taekels. See "Data change" for further contributors.
