- Country
- United States of America (USA)
- Manufacturer / Brand
- Hallicrafters, The; Chicago, IL and Arlington/Grand Prairie, TX
- Year
- 1950
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 245460
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 20
- Valves / Tubes
- 6J6 6J6 6J6 6AU6 6AU6 6AU6 12AU7 12AU7 6AU6 6AL5 6AV5 6AQ5 12AU7 6SN7 6SN7 6BQ6 6W4 1X2 5V4 16AP4
- Main principle
- Superheterodyne (common)
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 110-120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 519 - Hallicrafters, The; Chicago,
- Shape
- Tablemodel, with any shape - general.
- Notes
-
Television Receiver.
Tuning Range Channels 2 thru 13.
- Mentioned in
- Photofact Folder, Howard W. SAMS (Set 92 Folder 3 Date 4-50)
- Author
- Model page created by Geert Schulte. See "Data change" for further contributors.
