• Country
• United States of America (USA)

• Manufacturer / Brand
• Hallicrafters, The; Chicago, IL and Arlington/Grand Prairie, TX

• Year
• 1962/1963

• Category
• Commercial Receiver (may include amateur bands)

• Radiomuseum.org ID
• 81563

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 10

• Valves / Tubes
• 6ER5 6BL8 6BL8 6BL8 12BA6 12AT7 12BA6 6DT6 6BL8 12AQ5

• Main principle
• Superhet, double/triple conversion; ZF/IF 455 kHz

• Wave bands
• FM Broadcast Band Only

• Power type and voltage
• Alternating Current supply (AC) / 50-60 cycles, 105-125 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 3 inch = 7.6 cm

• Material
• Metal case

• from Radiomuseum.org
• Model: CRX-2 - Hallicrafters, The; Chicago,

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 13.5 x 5.75 x 8 inch / 343 x 146 x 203 mm

• Notes

• 2nd IF 10.7MHz, 2 silicon diode rectifiers, covering 151-174MHz, features vernier tuning drive, space for 2 switch selectable fixed frequency crystals

• Net weight (2.2 lb = 1 kg)
• 15.5 lb (15 lb 8 oz) / 7.037 kg

• Price in first year of sale
• 110.00 $

• Source of data
• Radios by hallicrafters

• Literature/Schematics (4)
• Sears, Roebuck Catalogs (Silvertone) (Spring/Summer 1963, page 1276. (Order=57A 7476C))
