Speech amplifier HT-5H
Hallicrafters, The; Chicago, IL and Arlington/Grand Prairie, TX
- Country
- United States of America (USA)
- Manufacturer / Brand
- Hallicrafters, The; Chicago, IL and Arlington/Grand Prairie, TX
- Year
- 1941–1945
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 263336
- Number of Tubes
- 8
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 105 - 125 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 2 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: Speech amplifier HT-5H - Hallicrafters, The; Chicago,
- Shape
- Boatanchor (heavy military or commercial set >20 kg).
- Dimensions (WHD)
- 420 x 210 x 260 mm / 16.5 x 8.3 x 10.2 inch
- Notes
-
The HT-5H is an audio speech amplifier designed as an accessory for the HT-4 ( Signal Corps BC-610 ), used as a preamplifier driving 2 Watts into the modulator of the transmitter.
Signal Corps number : BC-614.
Options : Carbon or dynamic microphone.
To be connected to BC-610 and JB-70 junction box..
- Net weight (2.2 lb = 1 kg)
- 14 kg / 30 lb 13.4 oz (30.837 lb)
- Price in first year of sale
- 70.00 USD
- Author
- Model page created by Michael Gnaedig-Fischer. See "Data change" for further contributors.
