Hurricane SR-2000

Hallicrafters, The; Chicago, IL and Arlington/Grand Prairie, TX

Data
Forum
Pictures
Collections

  • Year
  • 1965–1972
  • Category
  • Amateur TRX: Transmitter/Receiver (and Transceiver)
  • Radiomuseum.org ID
  • 80642

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 19
  • Main principle
  • Superhet, double/triple conversion; ZF/IF 1650 kHz
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Alternating Current supply (AC) / 115/230 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Hurricane SR-2000 - Hallicrafters, The; Chicago,
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 16.5 x 7.4 x 15 inch / 419 x 188 x 381 mm
  • Notes
  • Tubes continued: 8122, 0A2, 22 diodes, 2nd IF 6-6.5 MHz, covers 80 to 10 meter, input power 1000 to 2000 watts P.E.P. SSB and 900 watts CW, features includes VOX, MOX, PTT, AALC, product detector, crystal lattice filter, break-in CW keying, CW side-tone, crystal calibrator, full metering, noise blanker, RIT, two speed cooling fan, the power supply P-2000 is a seperate unit and contains the speaker and the final amplifier plate voltage and current meters, the power supply was priced seperately at 450 USD, optional accessory HA-20 VFO for seperate control of the transmitter and receiver frequencies.
  • Net weight (2.2 lb = 1 kg)
  • 11.8 kg / 25 lb 15.9 oz (25.991 lb)
  • Price in first year of sale
  • 1,095.00 $
  • Author
  • Model page created by a member from D. See "Data change" for further contributors.
