Safari FPM-300 Mark 2

Hallicrafters, The; Chicago, IL and Arlington/Grand Prairie, TX

Data
Forum
Pictures
Collections

  • Year
  • 1974–1977
perfect model
  • Category
  • Amateur TRX: Transmitter/Receiver (and Transceiver)
  • Radiomuseum.org ID
  • 80645

 Technical Specifications

  • Number of Tubes
  • 2
  • Number of Transistors
  • 33
  • Semiconductors
  • Main principle
  • Superheterodyne (common); ZF/IF 9000 kHz
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Line / Storage batteries (perhaps also batteries) / 105-125 / 210-250 / 11-15,5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Power out
  • 2 W (unknown quality)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Safari FPM-300 [Mark 2] - Hallicrafters, The; Chicago,
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 12.75 x 5.5 x 10.75 inch / 324 x 140 x 273 mm
  • Notes

  • 3 IC's, 3 bridge rectifiers, covers 80 through 10 meters, input power 250 watts P.E.P SSB, 180 watts CW, features VOX, PTT, crystal lattice filter, 25 KHz crystal calibrator, AALC, semi-automatic CW break-in, multi-purpose meter and built in 12 volt DC and 120 volt AC power supply, options include the HA-60 cooling fan and the MR-300 mobile mounting kit, same features as the FPM-300 but value changes in some of the smaller components and number of diodes used, the major difference is in the price and in the type of printed circuits switches used because there were problems with the original type used in the first production run, Mark 2 is stamped at the rear apron of the chassis.

  • Net weight (2.2 lb = 1 kg)
  • 11.3 kg / 24 lb 14.2 oz (24.89 lb)
  • Price in first year of sale
  • 625.00 $
  • Author
  • Model page created by a member from D. See "Data change" for further contributors.
