• Country
• United States of America (USA)

• Manufacturer / Brand
• Hallicrafters, The; Chicago, IL and Arlington/Grand Prairie, TX

• Year
• 1952/1953

• Category
• Commercial Receiver (may include amateur bands)

• Radiomuseum.org ID
• 77654

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 19

• Valves / Tubes
• 6AG5 6BA6 6BE6 6C4 6BE6 6BA6 6BA6 6BA6 6BA6 6BA6 6AL5 6AT6 6AL5 6BA6 6Y6 6AG5 6BA6 VR150 5U4

• Main principle
• Superhet, double/triple conversion; ZF/IF 6000/455 kHz; 2 AF stage(s)

• Wave bands
• Broadcast plus more than 2 Short Wave bands.

• Power type and voltage
• Alternating Current supply (AC) / 95-260 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 2 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: SX-73 [Production] - Hallicrafters, The; Chicago,

• Shape
• Rack

• Dimensions (WHD)
• 508 x 280 x 470 mm / 20 x 11 x 18.5 inch

• Notes

• Coverage 0.54-1.35, 1.35-3.45, 3.45-7, 7-14.4, 14.4-29.7, 29.7-54 MHz, 2nd IF 6000 kHz, double conversion, tunable hfo 7-54 MHz, single conversion 0.54-7 MHz, has 6 fixed crystal positions with crystal vernier tuning, designed for rack mounting, designed initially for the military-commercial market, ready for mounting in a 19" rack, Military version R274/FRR, similar to SP-600, Turret coil selector.

• Net weight (2.2 lb = 1 kg)
• 26.3 kg / 57 lb 14.9 oz (57.93 lb)

• Price in first year of sale
• 975.00 $

• Source of data
• Communications Receivers

• Mentioned in
• Shortwave Receivers - Past & Present (3rd ed.)

• Author
• Model page created by a member from D. See "Data change" for further contributors.
