T54

• Country
• United States of America (USA)

• Manufacturer / Brand
• Hallicrafters, The; Chicago, IL and Arlington/Grand Prairie, TX

• Year
• 1948/1949

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 97855

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 22

• Valves / Tubes
• 6AG5 6AG5 6C4 6AU6 6AU6 6AU6 6H6 6AU6 12SN7GT 6AU6 6AL5 6AV6 25L6GT 12SN7GT 12SN7GT 12SN7GT 12SN7GT 6C4 1B3GT 25Z6GT 6X5GT 7JP4

• Main principle
• Superhet with RF-stage; 2 AF stage(s)

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Alternating Current supply (AC) / 117 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Metal case

• from Radiomuseum.org
• Model: T54 - Hallicrafters, The; Chicago,

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 20 x 10.5 x 16 inch / 508 x 267 x 406 mm

• Notes
• The Hallicrafters model T54 is a 7" round tube TV with 13 VHF channels selectable with push buttons, includes also channel 1. Very similar with Type 514. The 1949 Catalog Walter Ashe Radio Co., St. Louis, MO., with 128 pages shows the model on page 60 - together with the Hallicrafter models T61, 505, T60 and T68.

• Price in first year of sale
• 170.00 $

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Set 91 Folder 6 Date 4-50)

• Author
• Model page created by a member from A. See "Data change" for further contributors.
