- Country
- United States of America (USA)
- Manufacturer / Brand
- Hallicrafters, The; Chicago, IL and Arlington/Grand Prairie, TX
- Year
- 1949 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 223454
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 23
- Valves / Tubes
- 6AG5 6AG5 6C4 6AU6 6AU6 6AU6 6AU6 6AL5 6AU6 6AQ5 12AU7 6AU6 6AL5 6AU6 6K6GT 6SN7GT 6AL5 6SN7GT 10BP4 6BG6G 1B3GT 5V4G 5U4G
- Main principle
- Superhet with RF-stage
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 5.87 inch = 14.9 cm
- from Radiomuseum.org
- Model: T64 - Hallicrafters, The; Chicago,
- Shape
- Tablemodel, high profile (upright - NOT Cathedral nor decorative).
- Notes
- 10" tabletop, push button 12 VHF channel selector,channel 2 through 13, dual chassis, similar model T61, T67, 509, 510.
- Source of data
- Photofact Folder, Howard W. SAMS
- Mentioned in
- Volume 7 Set #65 Folder 4913-7 07/49
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 158, folder 1, dated 1-52)
- Author
- Model page created by Friedrich Weber † 12.09.2014. See "Data change" for further contributors.
