T-68

Hallicrafters, The; Chicago, IL and Arlington/Grand Prairie, TX

Data

Forum

Pictures

Collections

Country
United States of America (USA)

Manufacturer / Brand
Hallicrafters, The; Chicago, IL and Arlington/Grand Prairie, TX

Year
1948/1949

Category
Television Receiver (TV) or Monitor

Radiomuseum.org ID
199112

Schematics

T-68; Hallicrafters, The; (ID = 1301608) Television — Hallicrafters, The; T-68 (3)

T-68; Hallicrafters, The; (ID = 1301609) Television — Hallicrafters, The; T-68 (3)

T-68; Hallicrafters, The; (ID = 1282783) Television — Hallicrafters, The; T-68 (3)

T-68; Hallicrafters, The; (ID = 1301610) Television — Hallicrafters, The; T-68 (3)

T-68; Hallicrafters, The; (ID = 1301611) Television — Hallicrafters, The; T-68 (3)

T-68; Hallicrafters, The; (ID = 1301613) Television — Hallicrafters, The; T-68 (3)

T-68; Hallicrafters, The; (ID = 1301614) Television — Hallicrafters, The; T-68 (3)

T-68; Hallicrafters, The; (ID = 1301616) Television — Hallicrafters, The; T-68 (3)

T-68; Hallicrafters, The; (ID = 1301617) Television — Hallicrafters, The; T-68 (3)

T-68; Hallicrafters, The; (ID = 1301618) Television — Hallicrafters, The; T-68 (3)

T-68; Hallicrafters, The; (ID = 1301619) Television — Hallicrafters, The; T-68 (3)

T-68; Hallicrafters, The; (ID = 1301620) Television — Hallicrafters, The; T-68 (3)

T-68; Hallicrafters, The; (ID = 1301621) Television — Hallicrafters, The; T-68 (3)

T-68; Hallicrafters, The; (ID = 1301622) Television — Hallicrafters, The; T-68 (3)

T-68; Hallicrafters, The; (ID = 1301623) Television — Hallicrafters, The; T-68 (3)

T-68; Hallicrafters, The; (ID = 1301624) Television — Hallicrafters, The; T-68 (3)

T-68; Hallicrafters, The; (ID = 1301625) Television — Hallicrafters, The; T-68 (3)

T-68; Hallicrafters, The; (ID = 1301626) Television — Hallicrafters, The; T-68 (3)

T-68; Hallicrafters, The; (ID = 1301627) Television — Hallicrafters, The; T-68 (3)

T-68; Hallicrafters, The; (ID = 1301628) Television — Hallicrafters, The; T-68 (3)

Click on the schematic thumbnail to request the schematic as a free document.

Technical Specifications

Number of Tubes
28

Valves / Tubes
6AK5 6AG5 6AK5 6AG5 6C4 6AU6 6AU6 6AU6 6AU6 6AL5 6AU6 6V6GT 6AQ5 6SN7GT 12AU7 6AU6 6AL5 6AU6 6K6GT 6SN7GT 6AL5 6SN7GT 6BG6G 5V4G 5U4G 6SR7 6BG6G 3NP4

Main principle
Superhet with RF-stage

Wave bands
VHF incl. FM and/or UHF (see notes for details)

Power type and voltage
Alternating Current supply (AC) / 105-125 Volt

Loudspeaker
Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 5.75 inch = 14.6 cm

Material
Wooden case

from Radiomuseum.org
Model: T-68 - Hallicrafters, The; Chicago,

Shape
Tablemodel, with any shape - general.

Notes
The 1949 Catalog Walter Ashe Radio Co., St. Louis, MO., with 128 pages shows the mode T68 on page 60 - together with the Hallicrafter models T61, T54, 505 and T60.

Projection Television Receiver Tuning Range Channels 2 through 13

Source of data
Photofact Folder, Howard W. SAMS

Mentioned in
Volume 7 Folder 4911-10 05/1949

Author
Model page created by Ernst Erb. See "Data change" for further contributors.
