TW-201 Ch= Mark 1

Hallicrafters, The; Chicago, IL and Arlington/Grand Prairie, TX

Data
Forum
Pictures
Collections

  • Year
  • 1954–1956
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 258266

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 4
  • Main principle
  • Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
  • Tuned circuits
  • 6 AM circuit(s)
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • Line / Batteries (any type) / Either AC: 60 Hz, 120V or DC: 120V or Batteries: 67.5 & 7.5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Leather / canvas / plastic - over other material
  • from Radiomuseum.org
  • Model: TW-201 Ch= Mark 1 - Hallicrafters, The; Chicago,
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Notes

  • The Hallicrafters TW-201 is an AC/DC/Battery operated 4 tube portable BC band receiver. The BC band frequency tuning range is 535 - 1620 kHz.  Has cowhide case and Selenium Rectifier.

    The following models use the same schematic with two chassis versions and common cabinets with four different cabinet colors:

    Model Chassis Chassis Differences Cabinet Color
    TW-200 Mark 1 - British Tan
    TW-201 Mark 1 - Dove Gray
    TW-202 Mark 1 - Forest Green
    TW-203 Mark 1 - Cherry Red
    TW-200A Mark 1A Uses C3 British Tan
    TW-201A Mark 1A Uses C3 Dove Gray
    TW-202A Mark 1A Uses C3 Forest Green
    TW-203A Mark 1A Uses C3 Cherry Red

    Note that the Beitman reference covers only the Mark 1 chassis and does not have C3.

  • Price in first year of sale
  • 30.00 $
  • Author
  • Model page created by John Kusching. See "Data change" for further contributors.
