HM-303-4

• Country
• Germany

• Manufacturer / Brand
• HAMEG GmbH, Frankfurt

• Year
• 1994 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 255803

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 1

• Valves / Tubes

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 100-240 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: HM-303-4 - HAMEG GmbH, Frankfurt

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 285 x 125 x 380 mm / 11.2 x 4.9 x 15 inch

• Notes

• 30 MHz Standard Oszilloskop.
  2 Kanäle, 5mV - 50V/cm, mit Dehnung x5 ab 1mV/cm,
  Zeitbasis 0,5S - 0,1µS/cm, mit Dehnung x10 bis 10nS/cm,
  Triggerung DC - 100 MHz, TV-Sync-Separator, Altern. Triggerung,
  Komponenten-Tester, 1kHz/1MHz Kalibrator, Overscan-Anzeige.
