• Country
• Germany

• Manufacturer / Brand
• HAMEG GmbH, Frankfurt

• Year
• 1984

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 162631

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Wave bands
• - without

• Power type and voltage
• Powered by external power supply or a main unit.

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 0.25 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: Milliohm Meter HM8014 - HAMEG GmbH, Frankfurt

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 135 x 68 x 228 mm / 5.3 x 2.7 x 9 inch

• Notes
• Hameg-Modularsystem
  6 Widerstandsmeßbereiche 200 mOHm - 20 kOHm
  Auflösung 0,1 mOHm
  Diodentestfunktion
  Akustische Meßgrößenkontrolle
  4 Punkt Messung
  Nur im Grundgerät HM 8001 zu benutzen

• Net weight (2.2 lb = 1 kg)
• 0.650 kg / 1 lb 6.9 oz (1.432 lb)

• Source of data
• -- Original prospect or advert

• Author
• Model page created by Eduard Abfalterer. See "Data change" for further contributors.
