330B

• Country
• United States of America (USA)

• Manufacturer / Brand
• Harman Kardon; New York

• Year
• 1974

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 157961

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC)

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 40 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 330B - Harman Kardon; New York

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 387 x 114 x 330 mm / 15.2 x 4.5 x 13 inch

• Notes

• AM/FM Stereo-Receiver with 20 W_RMS per channel into 8 Ω.
  Walnut enclosure optional.

  Made in Japan or Taiwan.

• Net weight (2.2 lb = 1 kg)
• 9.450 kg / 20 lb 13 oz (20.815 lb)

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
