• Country
• United States of America (USA)

• Manufacturer / Brand
• Harman Kardon; New York

• Year
• 1956 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 98335

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 7

• Valves / Tubes
• 12AT7 12AT7 6BE6 6BA6 6AU6 6AU6 6AL5

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: "Guide" A-200 - Harman Kardon; New York

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 9.5 x 5.25 x 8 inch / 241 x 133 x 203 mm

• Notes

• Harman-Kardon model A-200 is an AC Operated FM-AM Superheterodyne Tuner.FM-AM Tuner, mono

• Price in first year of sale
• 70.00 $

• Literature/Schematics (1)
• Allied Radio Catalog Nº 150, 1956

• Literature/Schematics (2)
• Photofact Folder, Howard W. SAMS (Set 328 Folder 5 dated 9-56)

• Author
• Model page created by Vitor Oliveira. See "Data change" for further contributors.
