Bluetooth Speaker ONYX STUDIO 7

Harman Kardon; New York

Data
Forum
Pictures
Collections

  • Year
  • 2020 ??
  • Category
  • Audio Amplifier or -mixer
  • Radiomuseum.org ID
  • 349730

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Loudspeaker + integr.Amplifier
  • Power type and voltage
  • Batteries / addl. power jack / Lítium-ion: 3.6 / 19 Volt
  • Loudspeaker
  • 3 Loudspeakers
  • Power out
  • 50 W (unknown quality)
  • Material
  • Various materials
  • from Radiomuseum.org
  • Model: Bluetooth Speaker ONYX STUDIO 7 - Harman Kardon; New York
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 268 x 302.5 x 159.5 mm / 10.6 x 11.9 x 6.3 inch
  • Notes

  • Bluetooth version: 4.2

    Support: A2DP 1.3, AVRCP 1.6

    Transmitters: woofer 1 x 120 mm, tweeter 2 x 25 mm

    Rated power: 1 x 50WRMS Bi-amp (AC mode)

    Frequency response: 50Hz - 20kHz (-6dB)

    Signal / noise ratio: 80dB A-weighted

    Power supply: 19V / 2A

    Battery type: Lithium-ion (3.6V/3250mAh, 11.70Wh)

    Battery charging time: 5 hours

    Music playback time: up to 8 hours (varies according to volume and music content)

    Bluetooth transmitter power: <9dBm (EIRP)

    Bluetooth transmitter frequency range: 2400-2483.5MHz

    Bluetooth transmitter modulation: GFSK, π/4 - DQPSK, 8DPSK

  • Net weight (2.2 lb = 1 kg)
  • 3.295 kg / 7 lb 4.1 oz (7.258 lb)
  • Mentioned in
  • -- Original-techn. papers.
