• Country
• United States of America (USA)

• Manufacturer / Brand
• Harman Kardon; New York

• Year
• 1970

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 161718

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 14

• Semiconductors
• 43024217 40408 40595 2N5232 40594 40636

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Hi-Fi equipment

• Power type and voltage
• Alternating Current supply (AC) / 120 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 120 W (undistorted)

• Material
• Metal case

• from Radiomuseum.org
• Model: Citation Twelve - Harman Kardon; New York

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 311 x 140 x 317 mm / 12.2 x 5.5 x 12.5 inch

• Notes

• Citation Twelve Stereophonic Power Amplifier.
  60 watts RMS per channel into 8 ohms.
  Each transistor type listed once only.

  Matching preamplifier: Citation Eleven.

  See also Citation twelve deluxe.

• Net weight (2.2 lb = 1 kg)
• 13.6 kg / 29 lb 15.3 oz (29.956 lb)

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
