• Country
• United States of America (USA)

• Manufacturer / Brand
• Harman Kardon; New York

• Year
• 1957

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 161702

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 8

• Valves / Tubes
• 12AT7 12AT7 6BE6 6BA6 6AU6 6AU6 6AL5 12AU7

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 60 Hz, 105 - 125 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Metal case

• from Radiomuseum.org
• Model: The Rondo T-120 - Harman Kardon; New York

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 12.5 x 3.25 x 8.75 inch / 318 x 83 x 222 mm

• Notes

• AM/FM Tuner Harman T-120.
  Armstrong circuit with Limiter & Foster-Seeley Discriminator. Automatic Frequency Control, Low Noise Front End consisting of Tuned Triode Grounded Grid Amplifier and Triode Mixer. Rumble Filter.
  Superheterodyne with A.V.C. and Ferrite Antenna - 10kHz Whistle Filter.
  Escutcheon: brushed copper. Cage: matt black. Edge lighted dial glass: yellow and white.
  Shipping weight 12 lbs.
  8 Tubes, Selenium Rectifier.



• Price in first year of sale
• 95.00 $

• Source of data
• -- Original prospect or advert

• Mentioned in
• Harman Kardon - The best seat in the Concert Hall - 1957 - page 10

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (SET 354, FOLDER 10, DATE 4-57)

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
