• Country
• Finland

• Manufacturer / Brand
• Harmon, Turku

• Year
• 1945

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 280071

• • alternative name: Radiokeskus Oy, Turku

• Number of Tubes
• 4

• Valves / Tubes
• ECH3 EBF11 ECL11 AZ11

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 220; 240 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 20 cm = 7.9 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: 654W - Harmon, Turku

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 520 x 335 x 225 mm / 20.5 x 13.2 x 8.9 inch

• Author
• Model page created by Timo Rantasaari. See "Data change" for further contributors.

• Other Models

• Here you find 36 models, 26 with images and 1 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
