- Country
- Italy
- Manufacturer / Brand
- Harmonic Radio; Milano
- Year
- 1951/1952
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 154575
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common)
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 145; 160; 220 Volt
- Loudspeaker
- Presumably Dynamic Loudspeaker (moving coil) / Ø 15 cm = 5.9 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: 642 - Harmonic Radio; Milano
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 540 x 280 x 230 mm / 21.3 x 11 x 9.1 inch
- Notes
- Gamme d'onda: 2 medie e 2 corte. Wave bands: 2x BC, 2x SW.
- Net weight (2.2 lb = 1 kg)
- 5.9 kg / 12 lb 15.9 oz (12.996 lb)
- Price in first year of sale
- 40,500.00 ITL
- Literature/Schematics (1)
- Catalogo Antique Radio, Vol. I (pag.349)
- Author
- Model page created by Fabio Zannier. See "Data change" for further contributors.
