• Country
• Germany

• Manufacturer / Brand
• Harting, Wilhelm; Espelkamp-Mittwald

• Year
• 1958/1959

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 22661

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 1

• Valves / Tubes
• ECL82

• Number of Transistors

• Semiconductors
• E250C50

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Rec.Player+Audio.Amp+LS

• Power type and voltage
• Alternating Current supply (AC) / 110; 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: Vagabund - Harting, Wilhelm; Espelkamp-

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 295 x 277 x 187 mm / 11.6 x 10.9 x 7.4 inch

• Notes
• Wechsler; nur 45 UpM; Kristall-System, 30-15000 Hz.

• Net weight (2.2 lb = 1 kg)
• 5 kg / 11 lb 0.2 oz (11.013 lb)

• Price in first year of sale
• 208.00 DM

• External source of data
• Erb

• Source of data
• HdB d.Rdf-& Ferns-GrH 1958/59 / Radiokatalog Band 2, Ernst Erb

• Literature/Schematics (1)
• -- Original-techn. papers.
