• Country
• Germany

• Manufacturer / Brand
• Hartmann & Braun AG; Frankfurt

• Year
• 1971 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 127007

• • Brand: Elima

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• Dry Batteries / 1,5 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Elavi 4 - Hartmann & Braun AG; Frankfurt

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 110 x 90 x 210 mm / 4.3 x 3.5 x 8.3 inch

• Notes

• Vielfachmessgerät, Gleichspannung 100 mV-5000 V, Wechselspannung 10 V-1000 V, Gleichstrom 50 µA-1 A, Widerstand 0-5 MOhm.

  Schaltplan siehe baugleiches Gerät Goertz Unigor 4P.

• Net weight (2.2 lb = 1 kg)
• 1 kg / 2 lb 3.2 oz (2.203 lb)

• Author
• Model page created by Ottmar Rollmann. See "Data change" for further contributors.
