Elavitron 2
Hartmann & Braun AG; Frankfurt
- Country
- Germany
- Manufacturer / Brand
- Hartmann & Braun AG; Frankfurt
- Year
- 1973 ?
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 354948
-
- Brand: Elima
Picture from manual
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Wave bands
- - without
- Power type and voltage
- Dry Batteries / N: 4 x 1,5 & AA: 1 x 1,5 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Elavitron 2 - Hartmann & Braun AG; Frankfurt
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 95 x 64 x 165 mm / 3.7 x 2.5 x 6.5 inch
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
