- Country
- United States of America (USA)
- Manufacturer / Brand
- Harvey Radio Labs., Harvey - Wells; Brookline, Southbridge, MA
- Year
- 1947 ?
- Category
- Commercial Transmitter & Receiver (TRX not Amateur)
- Radiomuseum.org ID
- 193955
SAMS Photofact
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 8
- Main principle
- Superheterodyne (common); ZF/IF 142.5 kHz
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 6 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Material
- Metal case
- from Radiomuseum.org
- Model: ATR-3-6 - Harvey Radio Labs., Harvey -
- Shape
- Chassis only or for «building in»
- Literature/Schematics (4)
- Photofact Folder, Howard W. SAMS (Set 36, Date 3/48, Folder 486-14)
- Author
- Model page created by Ernst Erb. See "Data change" for further contributors.
