• Country
• United States of America (USA)

• Manufacturer / Brand
• Heathkit (Brand), Heath Co.; Benton Harbor (MI)

• Year
• 1967 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 97380

• • alternative name: Heath Company

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 6GY8 6AU6 6AU6 6AU6 6BN8

• Main principle
• Superhet with RF-stage; ZF/IF 10700 kHz

• Tuned circuits
• 11 FM circuit(s)

• Wave bands
• FM Broadcast Band Only

• Details
• Hi-Fi equipment

• Power type and voltage
• Alternating Current supply (AC) / 110 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: FM Tuner AJ-63 - Heathkit Brand, Heath Co.;

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 340 x 150 x 180 mm / 13.4 x 5.9 x 7.1 inch

• Notes

• Mono FM-Tuner, with AFC.

• Net weight (2.2 lb = 1 kg)
• 5 kg / 11 lb 0.2 oz (11.013 lb)

• Price in first year of sale
• 236.00 DM

• Mentioned in
• Heathkit-Katalog, Sommer 1967

• Author
• Model page created by Trev Levick. See "Data change" for further contributors.
