• Country
• United States of America (USA)

• Manufacturer / Brand
• Heathkit (Brand), Heath Co.; Benton Harbor (MI)

• Year
• 1951 ?

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 80403

• • alternative name: Heath Company

Click on the schematic thumbnail to request the schematic as a free document.

• Power type and voltage
• Dry Batteries / 6 Volt

• Material
• Wooden case

• from Radiomuseum.org
• Model: Impedance Bridge IB-1B - Heathkit Brand, Heath Co.;

• Shape
• Tablemodel, high profile (upright - NOT Cathedral nor decorative).

• Dimensions (WHD)
• 260 x 410 x 180 mm / 10.2 x 16.1 x 7.1 inch

• Notes
• Bridge Indicator -100uA to +100uA, controls for D, Q, D-Q, RCL value, multiplier D/Q, multiplier RCL, generator DC/ext./1kHz.
