• Country
• United States of America (USA)

• Manufacturer / Brand
• Heathkit (Brand), Heath Co.; Benton Harbor (MI)

• Year
• 1960 ??

• Category
• Kit (Parts plus instruction) or building instructions only

• Radiomuseum.org ID
• 277289

• • alternative name: Heath Company

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• 6BE6 6BA6 6AT6 6C4 6AQ5 5Y3GT

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast and Short Wave (SW).

• Power type and voltage
• Alternating Current supply (AC)

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Radio Receiver EK-2 - Heathkit Brand, Heath Co.;

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Notes

• Sold as part of an educational course on "Basic Radio".

• Author
• Model page created by Gottfried Silberhorn. See "Data change" for further contributors.
