Regulated AC Power supply GWA-14-1

Heathkit (Brand), Heath Co.; Benton Harbor (MI)

Data
Forum
Pictures
Collections

  • Year
  • 1970 ?
  • Category
  • Kit (Parts plus instruction) or building instructions only
  • Radiomuseum.org ID
  • 278434
    • alternative name: Heath Company

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 1
  • Wave bands
  • - without
  • Power type and voltage
  • Alternating Current supply (AC) / 50 to 60 Hz, 120 or 220 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Regulated AC Power supply GWA-14-1 - Heathkit Brand, Heath Co.;
  • Shape
  • Tablemodel with Push Buttons.
  • Dimensions (WHD)
  • 5 x 3 x 6 inch / 127 x 76 x 152 mm
  • Notes

  • Heath company Kit

    Power Supply for the model GW-14A Citizen-Band Transceiver

    Output: 13,5 VDC 1A
    Input: 120 or 220 V 50/60 Hz, 35 W max

  • Net weight (2.2 lb = 1 kg)
  • 3.5 lb (3 lb 8 oz) / 1.589 kg
  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Rudolf Müller. See "Data change" for further contributors.
