Mohawk RX-1

• Country
• United States of America (USA)

• Manufacturer / Brand
• Heathkit (Brand), Heath Co.; Benton Harbor (MI)

• Year
• 1958–1964 ??

• Category
• Amateur-Receiver (amateur bands, may include broadcast bands)

• Radiomuseum.org ID
• 87905

• • alternative name: Heath Company

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 14

• Valves / Tubes
• 6BZ6 6CS6 12AT7 6BA6 6CS6 12AT7 6BA6 6BJ7 6CS6 12AT7 6AQ5 6BA6 6BA6 5V4 0A2

• Main principle
• Superhet, double/triple conversion; ZF/IF 1682/50 kHz

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 105-125 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Mohawk RX-1 - Heathkit Brand, Heath Co.;

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 19.5 x 11.85 x 16 inch / 495 x 301 x 406 mm

• Notes
• Heathkit HF-Receiver Mohawk RX-1.
  Coverage 160 to 10 meters HAM bands; Modes: AM, CW, SSB; IF selectivity 5, 3, 2, 1, 0.5 kHz; rejection tuning.
  Matches "Apache" transmitter.

• Net weight (2.2 lb = 1 kg)
• 30 kg / 66 lb 1.3 oz (66.079 lb)

• Price in first year of sale
• 275.00 $

• Source of data
• Heathkit: A Guide to Amateur Radio Products

• Author
• Model page created by Ernst Erb. See "Data change" for further contributors.

• Other Models

• Here you find 716 models, 700 with images and 506 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Heathkit (Brand), Heath Co.; Benton Harbor (MI)
