Vacuum Tube Voltmeter (VTVM) V-5A
Heathkit (Brand), Heath Co.; Benton Harbor (MI)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Heathkit (Brand), Heath Co.; Benton Harbor (MI)
- Year
- 1948
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 110348
-
- alternative name: Heath Company
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 2
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 110-125 / 1x1,5 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Vacuum Tube Voltmeter V-5A - Heathkit Brand, Heath Co.;
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 120 x 190 x 105 mm / 4.7 x 7.5 x 4.1 inch
- Notes
- 6 Messbereiche, 3–1000 V DC/AC, 10 Ohm–10 MOhm.
- Net weight (2.2 lb = 1 kg)
- 2.5 kg / 5 lb 8.1 oz (5.507 lb)
