- Country
- Germany
- Manufacturer / Brand
- Heli Gerätebau, Hempel KG; Limbach-Oberfrohna, (Ostd.)
- Year
- 1962 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 238576
-
- alternative name: Gerätebau Limbach VEB
- Brand: VEB Elektromechanik Mittweida
Stahlrohruntergestell fehlt
- Number of Tubes
- 8
- Main principle
- Superheterodyne (common); ZF/IF 460/10700 kHz
- Tuned circuits
- 8 AM circuit(s) 12 FM circuit(s)
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 110; 127; 220; 240 Volt
- Loudspeaker
- 2 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: R2 Ch= 3001F - Heli Gerätebau, Hempel KG;
- Shape
- Console, Highboy (legs > 50 %).
- Dimensions (WHD)
- 650 x 245 x 412 mm / 25.6 x 9.6 x 16.2 inch
- Notes
-
Abmessungen ohne Stahlrohruntergestell (fehlt beim Mustergerät)
- Author
- Model page created by Gerhard Wickern. See "Data change" for further contributors.
