Concertino 5187W

Oy Helvar; Helsinki

Data
Forum
Pictures
Collections

  • Year
  • 1952 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 234162

 Technical Specifications

  • Number of Tubes
  • 5
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Ready for FM, has Broadcast, Long Wave, several Short Wave.
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 125; 220; 240 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 18 cm = 7.1 inch
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Concertino 5187W - Oy Helvar; Helsinki
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 540 x 358 x 255 mm / 21.3 x 14.1 x 10 inch
  • Notes

  • This model is build with FM-extension (tubes 4x EF80). The basic model 5187W is started to build at the end of year 1950. FM-models are started to build at the end of year 1952 and later.



  • Author
  • Model page created by Timo Rantasaari. See "Data change" for further contributors.
