- Country
- Denmark
- Manufacturer / Brand
- Herofon (Herophon), Hede Nielsens Fabriker; Horsens
- Year
- 1951 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 331651
-
- alternative name: Hede Nielsen's Fabrikker A/S
Brochure ca 1951
Brochure ca 1951
- Number of Tubes
- 7
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Long Wave and 2 x Short Wave.
- Power type and voltage
- AC/DC-set
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 751U - Herofon Herophon, Hede
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 528 x 425 x 275 mm / 20.8 x 16.7 x 10.8 inch
- Notes
-
Wave bands:
LW = 750 - 2000 m
MW = 220 - 550 m
SW = 75 - 200 m
SW = 16 - 51 m
- Mentioned in
- -- Original prospect or advert
