Wide Range Oscillator 200CD late (4 tubes)
Hewlett-Packard, (HP); Palo Alto, CA
- Country
- United States of America (USA)
- Manufacturer / Brand
- Hewlett-Packard, (HP); Palo Alto, CA
- Year
- 1965 ??
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 145055
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 115; 230 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Wide Range Oscillator 200CD [late ] - Hewlett-Packard, HP; Palo Alto
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 7.3 x 11.5 x 14.3 inch / 185 x 292 x 363 mm
- Notes
-
See also Model HP 200CD early with 5 tubes.
Frequency range 5 - 600,000 Hz.
- Net weight (2.2 lb = 1 kg)
- 9 kg / 19 lb 13.2 oz (19.824 lb)
- Source of data
- - - Manufacturers Literature
- Mentioned in
- HP-Manual
- Author
- Model page created by Heribert Jung. See "Data change" for further contributors.
- Other Models
-
Here you find 393 models, 361 with images and 138 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Hewlett-Packard, (HP); Palo Alto, CA
Collections
The model Wide Range Oscillator is part of the collections of the following members.
Forum contributions about this model: Hewlett-Packard, HP;: Wide Range Oscillator 200CD
Threads: 1 | Posts: 1
"Um Muito Bem Hajam"
"A Todos podem sacar cópia do manual para os modelos com o perfix do nº de série igual ou inferior a 605 em:"
For all, you can upload the manual for this model with prefix same or older then 605 in:
www hparchive.com/Manuals/HP-200CD-Manual-SNP_605.PDF
Best Regards
H Capela
Hernani Capela, 11.Dec.10
