• Country
• United States of America (USA)

• Manufacturer / Brand
• Hewlett-Packard, (HP); Palo Alto, CA

• Year
• 1972

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 335744

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 110-120/220-240 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Digital Multimeter HP 34702A - Hewlett-Packard, HP; Palo Alto

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 6.25 x 3.75 x 10.125 inch / 159 x 95 x 257 mm

• Notes

• The 34702A Multimeter provides four ranges of DC and AC (1 V to 1,000 V ) plus 6 ranges of resistance measurement (from 100 Ω to 10 M Ω). The AC function covers 45Hz to 100kHz.  The multimeter module comes with the snap-together display. The model was also available with a rechargeable battery module between the upper display module (34740A) and the lower measurement module.

• Net weight (2.2 lb = 1 kg)
• 5 lb (5 lb 0 oz) / 2.270 kg

• Mentioned in
• HP Journal, August 1972

• Literature/Schematics (1)
• HP Journal March 1973

• Literature/Schematics (2)
• HP 3470 manual

• Author
• Model page created by Rich Post. See "Data change" for further contributors.
