Signalgenerator 606A has only tubes
Hewlett-Packard, (HP); Palo Alto, CA
- Country
- United States of America (USA)
- Manufacturer / Brand
- Hewlett-Packard, (HP); Palo Alto, CA
- Year
- 1959–1964
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 168333
- Number of Tubes
- 18
- Valves / Tubes
- 6AW8 12AT7 6CL6 6CL6 12AT7 12B4 12AT7 6AW8 12AT7 6AW8 12B4A 12B4A 12B4A 12B4A 12B4A 6AW8 12B4A 6AW8 5651A
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 115-230 Volt
- Material
- Metal case
- from Radiomuseum.org
- Model: Signalgenerator 606A [has only tubes] - Hewlett-Packard, HP; Palo Alto
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 500 x 310 x 340 mm / 19.7 x 12.2 x 13.4 inch
- Notes
- Dieses Gerät hat keine Transistoren. Frequenzbereich: 50 kHz bis 65 MHz. Modulation umschaltbar zwischen 400 Hz und 1000 Hz. Ausgangsspannung regelbar im Bereich von 0,1 µV bis 3 Volt.
- Net weight (2.2 lb = 1 kg)
- 22.8 kg / 50 lb 3.5 oz (50.22 lb)
- Source of data
- -- Original-techn. papers.
- Author
- Model page created by Jos Lauth. See "Data change" for further contributors.
