Transistor 7 OYK Ch= 4/02
Palmer, H.G. (HGP, H.G.P.) - H.G. Palmer; Sydney
- Country
- Australia
- Manufacturer / Brand
- Palmer, H.G. (HGP, H.G.P.) - H.G. Palmer; Sydney
- Year
- 1961–1963
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 241428
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 7
- Main principle
- Superheterodyne (common)
- Tuned circuits
- 5 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Dry Batteries / 9 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
- Power out
- 0.2 W (undistorted)
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: Transistor 7 OYK Ch= 4/02 - Palmer, H.G. HGP, H.G.P. - H.G
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 10 x 6.5 x 3 inch / 254 x 165 x 76 mm
- Notes
-
Made by K.G.H. Pty. Ltd. (Keith Graham Harris - Titan) for H.G. Palmer's
- Net weight (2.2 lb = 1 kg)
- 1.2 kg / 2 lb 10.3 oz (2.643 lb)
- Price in first year of sale
- 30.45 AUS £
- Mentioned in
- J. R. Publications "Television Service Handbook".
- Literature/Schematics (1)
- J.R. Publications Transistor Radio Service Handbook (A Series Handbook, Page M1.)
- Literature/Schematics (2)
- -- Original prospect or advert (The Canberra Times: 1 February, 1962, Page 15)
- Author
- Model page created by Stuart Irwin. See "Data change" for further contributors.
