95T1

His Master's Voice (N.Z.), Ltd., HMV; Wellington

Data
Forum
Pictures
Collections

  • Year
  • 1941 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 354481

 Technical Specifications

  • Number of Tubes
  • 5
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • Alternating Current supply (AC) / 50-60 Hz, 105-125; 200-250 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: 95T1 - His Master's Voice N.Z., Ltd.,
  • Shape
  • Tablemodel without push buttons, Mantel/Midget/Compact up to 14
  • Notes

  • HMV 95T1

    5-valve superhet broadcast (MW) mantel model receiver. Tuning range 540 - 1720 kHz.

    ARTS&P label "G" 1940-41.

    RCA - HMV Export model, Made in the USA.

  • Author
  • Model page created by Brian Stevens. See "Data change" for further contributors.
