• Country
• New Zealand-Aotearoa

• Manufacturer / Brand
• His Master's Voice (N.Z.), Ltd., HMV; Wellington

• Year
• 1947

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 347295

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 7

• Valves / Tubes
• KTW63 X65 KTW63 DH63 Y61 KT63 U50

• Main principle
• Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)

• Tuned circuits
• 7 AM circuit(s)

• Wave bands
• Broadcast and Short Wave (SW).

• Power type and voltage
• Alternating Current supply (AC) / 230 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Wooden case

• from Radiomuseum.org
• Model: Westminster 477D - His Master's Voice N.Z., Ltd.,

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 16 x 18.5 x 11 inch / 406 x 470 x 279 mm

• Notes

• 7-valve (including magic eye) superhet with RF stage table receiver with walnut cabinet and 6" x 9" elliptical speaker.

  Chassis believed to be the same as the following year Model 487D.

• Mentioned in
• The Golden Age of Radio in the Home 1986 (Page 144 (Model 487))

• Author
• Model page created by Brian Stevens. See "Data change" for further contributors.
