- Country
- Great Britain (UK)
- Manufacturer / Brand
- HMV (Brand), His Masters Voice, The Gramophone Company Ltd.; Middlesex
- Year
- 1957 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 146708
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 9
- Main principle
- Superheterodyne (common); ZF/IF 470/10700 kHz; 4 AF stage(s)
- Tuned circuits
- 6 AM circuit(s) 8 FM circuit(s)
- Wave bands
- Broadcast, (BC) Long Wave (LW), 2 x SW and FM or UHF.
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 195-255 Volt
- Loudspeaker
- 4 Loudspeakers
- Power out
- 12 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 1626 - HMV Brand, His Masters Voice,
- Shape
- Console with any shape - in general
- Dimensions (WHD)
- 35.5 x 34.75 x 19 inch / 902 x 883 x 483 mm
- Notes
- Auto-radiogram with 3 speed changer type 48540S. Crystal pick-up. Two 10.5 inch eliptical speakers, plus two 2.5 inch tweeters.
- Net weight (2.2 lb = 1 kg)
- 71 kg / 156 lb 6.2 oz (156.388 lb)
- Source of data
- -- Schematic
- Circuit diagram reference
- Radio and TV Servicing books (R&TVS) book
- Author
- Model page created by Keith Staines. See "Data change" for further contributors.
