- Country
- Great Britain (UK)
- Manufacturer / Brand
- HMV (Brand), His Masters Voice, The Gramophone Company Ltd.; Middlesex
- Year
- 1972
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 109374
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 8
- Main principle
- Superheterodyne (common); ZF/IF 472 kHz
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Dry Batteries / 9 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Power out
- 1 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: HMV 2175 - HMV Brand, His Masters Voice,
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 12.25 x 6.75 x 3 inch / 311 x 171 x 76 mm
- Notes
-
Elliptical loudspeaker 6 x 4 inch / 5 Ohm.
- Price in first year of sale
- 17.55 GBP
- Source of data
- -- Collector info (Sammler)
- Mentioned in
- Trader Service Sheet 3047/ 1972
- Literature/Schematics (1)
- -- Original-techn. papers. (ERT Service Chart 1852 July 20 1972)
- Author
- Model page created by John Koster. See "Data change" for further contributors.
