- Country
- Australia
- Manufacturer / Brand
- His Master's Voice (HMV, H.M.V.), EMI (Australia) Ltd.; Sydney, NSW
- Year
- 1938
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 167417
HMV model 400 from original sales brochure.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common); ZF/IF 460 kHz; 2 AF stage(s)
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- Alternating Current supply (AC) / 200; 240; 260 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 8 inch = 20.3 cm
- Power out
- 6 W (undistorted)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 400 Ch= 638D - His Master's Voice HMV, H.M.V.
- Shape
- Console, Lowboy (legs < 50 %).
- Notes
-
This model has a static limiter and two levels of selectivity.
- Price in first year of sale
- 32.55 Aus£
- Circuit diagram reference
- Australian Official Radio Service Manual Vol. I I
- Mentioned in
- -- Original prospect or advert
- Author
- Model page created by Stuart Irwin. See "Data change" for further contributors.
