- Country
- Great Britain (UK)
- Manufacturer / Brand
- HMV (Brand), His Masters Voice, The Gramophone Company Ltd.; Middlesex
- Year
- 1937
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 266813
Dial
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common); ZF/IF 465 kHz
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 195 - 255 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 8 inch = 20.3 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: 595 - HMV Brand, His Masters Voice,
- Shape
- Console with any shape - in general
- Dimensions (WHD)
- 29.5 x 30 x 17 inch / 749 x 762 x 432 mm
- Notes
-
Similar to Marconiphone 567
- Author
- Model page created by James Randell. See "Data change" for further contributors.
