• Country
• Australia

• Manufacturer / Brand
• His Master's Voice (HMV, H.M.V.), EMI (Australia) Ltd.; Sydney, NSW

• Year
• 1957/1958

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 290350

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 6BE6 6BA6 6AV6 6M5 6X4

• Main principle
• ZF/IF 457.5 kHz; 2 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast and Short Wave (SW).

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 220-250 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Caprice 32-4P Ch= 32 - His Master's Voice HMV, H.M.V.

• Shape
• Console with any shape - in general

• Dimensions (WHD)
• 38.5 x 33.75 x 17 inch / 978 x 857 x 432 mm

• Notes

• Dual-wave radiogram with 4-speed BSR UA8 record changer. Cabinet finishes in walnut or rosewood.

  Speakers: Magnavox 10P1 and EMI 5-7PB.

  See also Kelvinator Riviera 32-K4P and earlier HMV Caprice 32-4E with 3-speed Collaro RC54 record changer.

• Net weight (2.2 lb = 1 kg)
• 77 lb 0 oz (77 lb) / 34.958 kg

• Price in first year of sale
• 114.45 AUS £

• Mentioned in
• Mingay's Price Service (Nov 1957 to Nov 1958.)

• Literature/Schematics (1)
• -- Original-techn. papers. (HMV Service Manual for Chassis Type 32.)

• Literature/Schematics (2)
• Australian Official Radio Service Manual AORSM (Volume 13, 1955 (for 1954 models), Page 140.)

• Author
• Model page created by Martin Kent. See "Data change" for further contributors.
