• Country
• Great Britain (UK)

• Manufacturer / Brand
• HMV (Brand), His Masters Voice, The Gramophone Company Ltd.; Middlesex

• Year
• 1938 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 349192

• Number of Tubes
• 5

• Valves / Tubes
• 6A8 6K7 6Q7 6F6 5Y3

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 50-100 Hz,100-117/118-130/195-223/224-255 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 15 cm = 5.9 inch

• Power out
• 2 W (2.5 W max.)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Fluid-Light Five 671 - HMV Brand, His Masters Voice,

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 575 x 280 x 230 mm / 22.6 x 11 x 9.1 inch

• Author
• Model page created by Matthew Xenakis. See "Data change" for further contributors.

• Other Models

• Here you find 425 models, 335 with images and 242 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
