42-K71 Ch=42-K
Kelvinator; Keswick, South Australia
- Country
- Australia
- Manufacturer / Brand
- Kelvinator; Keswick, South Australia
- Year
- 1955
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 195889
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 457.5 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast plus more than 2 Short Wave bands.
- Power type and voltage
- Alternating Current supply (AC) / 200-225; 226-250 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Bakelite case
- from Radiomuseum.org
- Model: 42-K71 Ch=42-K - Kelvinator; Keswick, South
- Dimensions (WHD)
- 16 x 10.25 x 9.125 inch / 406 x 260 x 232 mm
- Notes
-
Rebadged HMV model 42-71. Apart from some minor cosmetic differences, is otherwise indentical.
This model has three short wave bands covering 5.9-7.5 MHz, 9.4-12.1 MHz and 14.2 to 18.4 MHz.
- Net weight (2.2 lb = 1 kg)
- 18 lb 4 oz (18.25 lb) / 8.286 kg
- Price in first year of sale
- 44.10 AUS £
- Circuit diagram reference
- Australian Official Radio Service Manual Vol. XIV
- Literature/Schematics (1)
- J.R. Publications Radio Service Handbook (R.V. Series Vol. 1, 1963, Page H68.)
- Author
- Model page created by Stuart Irwin. See "Data change" for further contributors.
