CSK-310 Ch= TN-R1
Hitachi Ltd.; Tokyo
- Country
- Japan
- Manufacturer / Brand
- Hitachi Ltd.; Tokyo
- Year
- 1986 ?
- Category
- Car Radio, perhaps also + sound player/recorder
- Radiomuseum.org ID
- 336321
-
- alternative name: Hitachi Sales Corp. of America
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 45
- Semiconductors
- Main principle
- PLL, Phase-locked loop; ZF/IF 450/10700 kHz
- Wave bands
- Broadcast, Long Wave and FM or UHF.
- Details
- Cassette-Recorder or -Player
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 24 W (undistorted)
- Material
- Metal case
- from Radiomuseum.org
- Model: CSK-310 Ch= TN-R1 - Hitachi Ltd.; Tokyo
- Shape
- Chassis only or for «building in»
- Dimensions (WHD)
- 179 x 50 x 150 mm / 7 x 2 x 5.9 inch
- Notes
-
Auto Reverse Cassette Player with LW/MW/FM Electronic Tuner CSK-310
Wavebands:
- LW = 153 - 299 kHz
- MW = 531 - 1611 kHz
- UKW/FM = 87.5 - 108 MHz
- Net weight (2.2 lb = 1 kg)
- 1.5 kg / 3 lb 4.9 oz (3.304 lb)
- Mentioned in
- - - Manufacturers Literature
- Author
- Model page created by Peter Löytynoja. See "Data change" for further contributors.
