Solid State FM/AM Radio & Cassette KCT-1200C

Hitachi Ltd.; Tokyo

Data
Forum
Pictures
Collections

  • Year
  • 1970 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 235774
    • alternative name: Hitachi Sales Corp. of America

 Technical Specifications

  • Number of Transistors
  • 12
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Details
  • Cassette-Recorder or -Player
  • Power type and voltage
  • Line / Batteries (any type) / 110; 220 / 4 x 1,5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Power out
  • 1 W (max.)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Solid State FM/AM Radio & Cassette KCT-1200C - Hitachi Ltd.; Tokyo
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 11.7 x 7.8 x 3.4 inch / 297 x 198 x 86 mm
  • Notes

  • Hitachi Portable FM/AM Radio & Cassette All Transistor Model KCT-1200C.
    Frequency Range: FM 88 - 108 MHz, AM 530 - 1605 kHz.
    Made in Japan.

  • Net weight (2.2 lb = 1 kg)
  • 2.7 kg / 5 lb 15.2 oz (5.947 lb)
  • Mentioned in
  • Praktiker, Nr. 5/1970, Seite 27
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
